06 Clustering

Question 1

General objective of clustering

Question 2

Example applications of cluster analysis

Answer 2

• Visualization and exploratory data analysis
• Many applications within IR. Examples:

  • Speed up search: First retrieve the most relevant cluster, then retrieve documents from within the cluster.
  • 􏰁Presenting the search results: Instead of ranked lists, organize the results as clusters.
• Dimensionality reduction / class-based features.
• 􏰁News aggregation / topic directories.
• 􏰁Social network analysis; identify sub-communities and user segments.
• 􏰁Image segmentation, product recommendations, demographic analysis,

Question 3

Main types of clustering methods

Answer 3

• Hierarchical
• Flat (partitional clustering)

Question 4

k-means

Answer 4

• 􏰁Unsupervised variant of the Rocchio classifier.
• 􏰁Goal: Partition the n observed objects into k clusters C so that each point ⃗xj belongs to the cluster ci with the nearest centroid μ⃗i.
• 􏰁Typically assumes Euclidean distance as the similarity function s.
• 􏰁The optimization problem: For each cluster, minimize the within-cluster sum of squares, Fs = WCSS
• 􏰁Equivalent to minimizing the average squared distance between objects and their cluster centroids (since n is fixed) – a measure of how well each centroid represents the members assigned to the cluster.

Question 5

k-means (algorithm and properties)

Answer 5

Algorithm

• Initialize: Compute centroids for k seeds.
• Iterate:

  • Assign each object to the cluster with the nearest centroid.
  • Compute new centroids for the clusters.
• Terminate: When stopping criterion is satisfied.

Properties

• 􏰁In short, we iteratively reassign memberships and recompute centroids until the configuration stabilizes.
• 􏰁WCSS is monotonically decreasing (or unchanged) for each iteration.
• 􏰁Guaranteed to converge but not to find the global minimum.
• 􏰁The time complexity is linear, O(kn)

Question 6

k-means: Possible termination criterions

Answer 6

• Fixed number of iterations
• Clusters or centroids are unchanged between iterations
• Threshold on the decrease of the objective function (absolute or relative to previous iteration)

Question 7

Some close relatives of k-means

Answer 7

• k-medoids: Like k-means but uses medoids instead of centroids to represent the cluster centers
• Fuzze c-means (FCM): Like k-means but assigns soft memberships in [0, 1], where membership is a function of the centroid distance.

  • The computations of both WCSS and centroids are weighted by the membership function.

Question 8

Flat Clustering: The good and the bad

Answer 8

+ Conceptually simple, and easy to implement
+ Efficient. Typically linear in the number of objects.

• The dependence on random seeds as in k-means makes the clustering non-deterministic.
• The number of clusters k must be pre-specified. Often no principled means of a priori specifying k.
• The clustering quality often considered inferior to that of the less efficient hierarchical methods.
• Not as informative as the more stuctured clusterings produced by hierarchical methods.

Question 9

k-means clustering can be thought of as performing _____ in each iteration.

Answer 9

k-means clustering can be thought of as performing Rocchio classification in each iteration.
