Lower extremities

Question 1

Patient comes in with Hx of MM tear, which anatomy part will you scan?

a. Hip
b. bony pelvis
c. knee
d. ankle

Answer 1

c. knee

Question 2

Where is Fibula located in relation to the Tibia in coronal view?

a. Anterior
b. Posterior
c. Lateral
d. Medial

Answer 2

c. Lateral

Question 3

The purpose of magnetic resonance angiography is to image the:

a. Stationary soft tissue.
b. Blood flow.
c. Vessel lumen.
d. Only abnormal vessels

Answer 3

b. Blood flow.

Question 4

When selecting only one slice at a time during a pulse sequence, which method for providing spatial localization is employed?
a. 3DFT.
b. FFT.
C.FT.
d. 2DFT.

Answer 4

d. 2DFT.

Question 5

What makes up mortice angle?

a. Tibia, Fibula
b. Tibia, Fibula, Talus
c. Tibia, Fibula, Talus, Os Calcus

Answer 5

b. Tibia, Fibula, Talus

Question 6

When patient comes in with Hx of AVN of hip which bone will be concern of AVN?

a. Neck of the Femur
b. Head of the Femur
c. Greater tuberosity
d. lesser tuberosity

Answer 6

b. Head of the Femur

Question 7

7. What is the name of the strongest tendon in the body?
   a. Solaus Tenden
   b. Achillies
   c. Extensor Digitorus Longus

Answer 7

b. Achillies

Question 8

8. What is longest nerve in the body?
   a. Lumbar Plexus
   b. Pelvic Plexus
   c. Femoral Nerve
   d. Sciatic

Answer 8

d. Sciatic

Question 9

9. What is the longest muscle in the body?
   a. Sartorius muscle
   b. gastroenemius muscle
   c. Soleus muscle

Answer 9

a. Sartorius muscle

Question 10

10. Where does the head of the Femur resides in the body?
    a. Obturator foramen
    b. Acetabulum
    c. Ischium

Answer 10

b. Acetabulum

Question 11

Which tendon attaches to the Tuberosity of 5th Metatarsal?

a. Peroneal tendon
b. Perotenal tendon
c. Posterior tibilas tendon
d. Anterior tibilas tendon

Answer 11

a. Peroneal tendon

Question 12

12. Which tendon attaches posterior to the Os Calcus?
    a. Peroneal tendon
    b. Achillies tendon
    c. Plantar fascia tendon
    d. Talofibular tendon

Answer 12

b. Achillies tendon

Question 13

13. What passes through the tarsal tunnel?
    a. Tibialis posterior, Flexor Digitorum and hallucis longus, posterior tibilal vessels and nerve
    b. Extensor Tendon, Tibial Nerve, Fibular nerve
    C. Tibial nerve, Flexor Tendon,

Answer 13

C. Tibial nerve, Flexor Tendon,

Question 14

What is the name of the artery next to Femoral Artery?
a. Lateral Femoral artery
b. Medial Femoral artery
C. Profundas femorus artery
d. Popliteal artery

Answer 14

C. Profundas femorus artery

Question 15

Which nerve courses through the Tarsal tunnel?
a. Fibular
b. Tibial
C. Solus
d. Hollicus longus

Answer 15

b. Tibial

Question 16

Which tendon attaches inferior to the Os Calcus?

a. Peroneal tendon
b. Achillies tendon
c. Plantar fascia tendon
d. Talofibular tendon

Answer 16

c. Plantar fascia tendon

Question 17

17. What anatomical plain is the image in?
    a. Axial
    b. Sagittal

C. coronal

Answer 17

C. coronal

Question 18

What kind of exam is this?

a. Wrist
b. Ankle

C. foot

Answer 18

C. foot

Question 19

What is the anatomical plain for the image above?

a. Axial
b. Sagittal
c. coronal

Answer 19

b. Sagittal

Question 20

What anatomy is arrow 1 is pointing at?

a. Tibia
b. Fibula
c. Talus

Answer 20

b. Fibula

Question 21

What anatomy is arrow 2 is pointing at?

a. Pealajurti tendon
b. Peroneal tendon

c achillies tendon

d. Tibialis tendon

Answer 21

b. Peroneal tendon

Question 22

What anatomy is arrow 3 is pointing at?

a. 15 metacarpal tuberosity
b. 5 metatarsal tuberosity

C 15 melatarsal tuberosity

Answer 22

b. 5 metatarsal tuberosity

Question 23

23. label #1
24. label #2

Key for 23-24 A medial meniscus B. lateral meniscus C. Tibia D. Fibula

Answer 23

23. B. lateral meniscus
24. D. Fibula

Question 24

25. Label #1
26. Label #2

Answer 24

25. PCL
26. ACL

Question 25

27. What artifact is seen on this image? Pick the best answer a. motion b. pulsatile flow motion c. ringing 28. What is causing the artifact? Pick the best answer a. ringing from motion b. arterial flow causing artifact c. vein flow causing artifact

Answer 25

27. b. pulsatile flow motion 28. b. arterial flow causing artifact

Question 26

29. Label the torn Tendon a. Peroneal tendon b. Achilles tendon c. Plantar fascia d. Flexor tendon

Answer 26

b. Achilles tendon

Question 27

Label the missing artery a. Femoral artery b. Anterior tibial artery c. Popliteal artery

Answer 27

c. Popliteal artery

Question 28

31. What is this area called? 32. What is the name of the ligament that attaches here? 33. What is the anatomical plain? **Answer Key:** a. Tibialis lateralis tendon b. Peroneal tendon c. 1st tuberosity d. 5th tuberosity e. Axial f. Coronal

Answer 28

31. d. 5th tuberosity 32. b. Peroneal tendon 33. e. Axial

Question 29

Label the bone with arrow above image a. Navicular b. cuboid c. 1st cuneiform

Answer 29

c. 1st cuneiform

Question 30

35. Label the bone with the arrow a. Head 2nd of metatarsal b. Base 2nd of metatarsal c. Shaft of 3rd metatarsal d. Cuboid e. Navicular

Answer 30

a. Head 2nd of metatarsal

Question 31

36. Label the bone with the #1 37. Label the bone with the #2 a. Head 2nd of metatarsal b. Base 2nd of metatarsal c. Shaft of 3rd metatarsal d. Cuboid e. Navicular

Answer 31

36. e. Navicular 37. c. Shaft of 3rd metatarsal

Question 32

38. Label the anatomy with arrow #1 39. Label what tendon is torn in 2nd image? 40. Label the torn tendon on image with #3 on this page? 41. Label the anatomy with arrow #3 **Answer key** a. Tibial tuberosity b. Patellar ligament c. Quadriceps tendon d. ACL e. PCL

Answer 32

38. b. Patellar ligament 39. c. Quadriceps tendon 40. d. ACL

Question 33

42. What anatomy is #42 pointing at? 43. What anatomy is#43 pointing at? 44. What anatomy is #44 pointing at? A Fibular artery B. Anterior tibial artery C. Posterior tibial artery D. patellar artery

Answer 33

42. C. Posterior tibial artery 43. B. Anterior tibial artery 44.

Question 34

45. What anatomy is arrow pointing at? a. sesamoid bone fx b. planter plate c. neuroma

Answer 34

b. planter plate

Question 35

46. Label the anatomy 47. Label the anatomy **Answer key** a. Head of femur b. Acetabula c. Ischium d. Symphasis pubis

Answer 35

46. d. Symphasis pubis 47. a. Head of femur

Question 36

48. Label the anatomy 49. Label the anatomy **Answer key** a. Plantar fascia b. Talus c. Tibia d. Hallicus longus

Answer 36

48. b. Talus 49. a. Plantar fascia

Question 37

What is the arrow pointing at on #50? a. fat sat failure b. metal artifact c. dielectric artifact d. AVN

Answer 37

b. metal artifact
