Practice Q's - SPAN

Question 1

A question about how SPAN will react to EtherChannel?

1. Source port will be monitored.
2. Destination port will be excluded while the monitor session is active.
3. ???
4. ???

Answer 1

Correct Answer: A

Question 2

Refer to exhibit. (none)

monitor session 1 source remote vlan 8 – 10 monitor session 1 destination interface fa0/1

1. The packet is send to VLAN 8 and 10 and will be received in fa0/1.
2. The packet is received from VLAN 8 and 10 and will be send to fa0/1.
3. The packet is send to VLAN 8 to 10 and will be received in fa0/1.
4. The packet is received from VLAN 8 to 10 and will be send to fa0/1.

Answer 2

Correct Answer: D

Question 3

Which statement about VSPAN is true?

1. It can monitor ingress and egress traffic on the source VLAN.
2. It sends all VLAN traffic to the destination port regardless of the VLAN’s status.
3. It can monitor destination port traffic that belongs to a source VLAN.
4. It can monitor token ring VLANs.

Answer 3

Correct Answer: A

Question 4

Which two commands configure RSPAN to capture incoming and outgoing traffic on a single interface? (Choose two.)

1. monitor session 1 source interface gigabitethernet 1/0/2 both
2. monitor session 1 destination remote vlan 910
3. ???
4. ???
5. ???

Answer 4

Correct Answer: AB

Question 5

Which statement about SPAN functionality for an EtherChannel group is true?

1. It can be configured as a SPAN source or a SPAN destination port.
2. It can be configured as a SPAN source but not as a SPAN destination port.
3. It can be configured as a SPAN destination but not as a SPAN source port.
4. It cannot be configured as a SPAN source or a SPAN destination port.

Answer 5

Correct Answer: B

Question 6

What happens if an interface within channel group is configured as SPAN destination?

1. Portchannel will forward traffic to source SPAN.
2. It will not be operational.
3. The link will be in error-disable.
4. The interface will be removed from the channel group.

Answer 6

Correct Answer: D

Question 7

How does SPAN interact with STP?

1. A designed SPAN source port maintains its STP learning status.
2. STP is disabled on a destination port when a SPAN monitor session is active.
3. STP is disabled on trunk ports carrying the SPAN VLAN.
4. Designated SPAN source ports direct traffic to the root bridge of STP.

Answer 7

Correct Answer: B

Question 8

Which command sequence do you enter to configure an RSPAN VLAN?

1. vlan 51, name RSPAN
2. vlan 51, remote-span
3. vlan 4097, remote-span
4. vlan 4097, name RSPAN

Answer 8

Correct Answer: B
