Yr 3 - Skills & Extras > AXR Interpretation > Flashcards

AXR Interpretation Flashcards

(72 cards)

Study These Flashcards
1
Q

Give an overall structure of interpreting a CXR

A
  1. Confirm patient details
  2. Confirm date and time film was taken
  3. Request previous imaging for comparison (if necessary)
  4. Assess projection
  5. Assess exposure
  6. Bowel and other organs
  7. Bones
  8. Calcifications and artefact
  9. Presentation
How well did you know this?
1
Not at all
2
3
4
5
Perfectly
2
Q

Label the structures

A

Top left → liver edge

Bottom left → kidney

Top right → spleen

Middle right → stomach

Bottom right → psoas

How well did you know this?
1
Not at all
2
3
4
5
Perfectly
3
Q

Label the structures

A

Top → large bowel

Middle → small bowel

Bottom → bladder

How well did you know this?
1
Not at all
2
3
4
5
Perfectly
4
Q

What is the typical projection of an abdominal XR?

A
  • Anterior posterior (AP) supine → most common
  • Anterior posterior (AP) erect
How well did you know this?
1
Not at all
2
3
4
5
Perfectly
5
Q

Why do AXRs not provide a good view of posterior abdominal structures?

A

due to overlying bowel and gas

How well did you know this?
1
Not at all
2
3
4
5
Perfectly
6
Q

If bowel perforation is considered, which imaging would be useful?

A

An erect CXRT is more useful to see free gas under the diaphragm (patient needs to have sat upright for at least 15-20 minutes prior to XR to allow time for air to rise).

How well did you know this?
1
Not at all
2
3
4
5
Perfectly
7
Q

Where does the small bowel lie in relation to the large bowel on an AXR?

A

Small bowel usually lies more centrally, with the large bowel framing it

How well did you know this?
1
Not at all
2
3
4
5
Perfectly
8
Q

What are the mucosal folds of the small bowel called?

A

Valvulae conniventes

How well did you know this?
1
Not at all
2
3
4
5
Perfectly
9
Q

What are valvulae conniventes also known as?

A

Plicae circulares

How well did you know this?
1
Not at all
2
3
4
5
Perfectly
10
Q

Do the valvulae conniventes of the small bowel appear to cross the full width of the lumen on an AXR?

A

Yes

How well did you know this?
1
Not at all
2
3
4
5
Perfectly
11
Q

Which parts of the large bowel are retroperioneal?

A

Ascending colon, descending colon, and rectum

How well did you know this?
1
Not at all
2
3
4
5
Perfectly
12
Q

If visible, which is the widest segment of the colon?

A

Caecum → 9cm

How well did you know this?
1
Not at all
2
3
4
5
Perfectly
13
Q

The longitudinal muscles (taenia coli) and circular muscles of the colon form sacculations/pouches called what?

A

Haustra

How well did you know this?
1
Not at all
2
3
4
5
Perfectly
14
Q

What are found in between the haustra?

A

Plicae semilunaris

How well did you know this?
1
Not at all
2
3
4
5
Perfectly
15
Q

Are haustra thicker or thinner than the valvulae conniventes of the small bowel?

A

Thicker

How well did you know this?
1
Not at all
2
3
4
5
Perfectly
16
Q

Do the haustra completely traverse the large bowel

A

No

How well did you know this?
1
Not at all
2
3
4
5
Perfectly
17
Q

Are faeces typically seen in the small or large bowel?

A

Large bowel

How well did you know this?
1
Not at all
2
3
4
5
Perfectly
18
Q

Give the appearance of faeces on an AXR

A

Faeces have a mottled appearance due to trapped gas in colon.

How well did you know this?
1
Not at all
2
3
4
5
Perfectly
19
Q

What are the upper limits for the normal diameter of different bowel segments on an AXR?

A

3/6/9 rule

  • Small bowel → 3cm
  • Colon → 6cm
  • Caecum → 9cm
How well did you know this?
1
Not at all
2
3
4
5
Perfectly
20
Q

What would a small bowel dilatation (>3cm diameter) indicate?

A

Small bowel obstruction

How well did you know this?
1
Not at all
2
3
4
5
Perfectly
21
Q

Give some AXR features of a SBO

A
  • Dilation of small bowel (>3cm diameter)
  • Much more prominent valvulae conniventes – create a ‘coiled-spring’appearance
How well did you know this?
1
Not at all
2
3
4
5
Perfectly
22
Q

What is the most common cause of SBO in the developed world?

A

Adhesions (75%)

How well did you know this?
1
Not at all
2
3
4
5
Perfectly
23
Q

Give some other causes of SBO

A
  • Adhesions (75%)
  • Abdominal hernias (10%)
  • Intrinsic or extrinsic compression by neoplastic masses
How well did you know this?
1
Not at all
2
3
4
5
Perfectly
24
Q

When interpreting an AXR, which region should you always inspect if considering a hernia as a cause of SBO?

A

Inguinal region

How well did you know this?
1
Not at all
2
3
4
5
Perfectly
25
Give 2 major causes of large bowel obstruction (LBO)
* Colorectal carcinoma * Diverticular strictures
26
Give 2 minor causes of LBO
1. Hernias 2. Volvulus
27
What is volvulus?
Twisting of the bowel on its mesentery → Results in partial or complete obstruction
28
Where does volvulus usually occur in the colon?
Sigmoid colon or the caecum
29
What are potential complications of volvulus of the colon?
Patients at high risk of **bowel** **perforation** (? sepsis) and/or **bowel** **ischaemia** 2ary to vascular compromise
30
What is ileus?
Ileus is a temporary lack of the normal muscle contractions of the intestines e.g. certain drugs. This can lead to a build-up and potential blockage of food material.
31
What is the characteristic feature of **sigmoid** volvulus?
Coffee bean appearance
32
SBO vs paralytic ileus
33
Is sigmoid or caecal volvulus more common?
Sigmoid - accounts for up to 80% of all intestinal obstructions
34
Who is volvulus more common in?
Most common in elderly persons (often neurologically impaired)
35
What is typically seen in the PMH of a patient with sigmoid volvulus?
Chronic constipation
36
Treatment of sigmoid volvulus?
* **Decompression** with rectal flatus tube or sigmoidoscope if no signs of bowel ischaemia or perforation * **Laparoscopic** **derotation** or laparotomy +/- bowel resection * Caecopexy suture fixation of bowel to peritoneum may prevent recurrence
37
Sigmoid volvulus XR:
38
Caecal volvulus XR:
39
is extra-luminal gas ever normal?
no
40
In healthy individuals, which wall of the bowel should be visible on a AXR?
Inner wall only
41
What is Rigler's sign? What does it indicate?
The presence of **free air** within the abdomen (pneumoperitoneum) can result in **both sides of the bowel wall** becoming visible (this is known as Rigler’s sign) → gas outlines bowel.
42
Give 2 major causes of a pnuemoperitoneum
1. Perforated abdominal viscus 2. Recent abdominal surgery
43
What can cause a perforation of an abdominal viscus?
* Diverticular disease with rupture of diverticulum * Perforated gastric or duodenal ulcer * Trauma * Obstruction * IBD with ruptured bowel
44
What does the ‘football’ sign indicate?
The **football sign** is seen in cases of massive [pneumoperitoneum](https://radiopaedia.org/articles/pneumoperitoneum?lang=gb), where the abdominal cavity is outlined by gas from a perforated viscus. The abdomen appears as a **large oval radiolucency reminiscent** of an American football
45
What is Chilaiditi's Sign?
Interposition of the bowel, usually colon, between the inferior surface of the **right diaphragm and the superior surface of the liver**
46
What is Chilaiditi's sign often misdiagnosed as?
Often misdiagnosed as a true pneumoperitoneum resulting in unnecessary investigations/treatment
47
What is Chilaiditi's syndrome?
Chilaiditi syndrome is a rare condition when **_pain_** occurs due to **transposition of a loop of large intestine** (usually transverse colon) in between the **diaphragm** and the **liver**, visible on an AXR. Normally this causes no symptoms, and this is called **Chilaiditi's** sign.
48
Give 3 potential AXR features seen in IBD
1. Thumbprinting 2. Leadpipe colon 3. Toxic megacolon
49
What is ‘thumbprinting'?
Mucosal thickening of the haustra due to inflammation and oedema causing them to appear like thumbprints projecting into the lumen
50
What is a ‘leadpipe colon’?
loss of normal haustral markings 2ary to chronic colitis
51
What is toxic megacolon?
It is defined as a **_non-obstructive_** dilation of the colon, which can be total or segmental and is usually associated with **systemic** **toxicity**.
52
What is the main cause of toxic megacolon?
IBD
53
Complications of toxic megacolon?
Perforation, sepsis, death
54
Give some examples of soft tissue structures visible on an AXR
* Lung bases * Liver * Gallbladder * Stomach * Psoas muscles * Kidneys * Spleen * Bladder
55
Why should you ensure to inspect the lung bases in an AXR?
as abdominal pain can sometimes be caused by basal pneumonia → check for **consolidation**
56
Where is the liver seen in an AXR?
RUQ
57
Is the gallbladder normally visible on an AXR?
rarely visible on AXR but quickly inspect for **calcified** **gallstones** and **cholecystectomy** **clips**
58
Where is the stomach usually visible on an AXR?
Between the LUQ and midline
59
Where are the psoas muscles typically visible?
lateral edge is marked by a relatively straight line either side of the lumbar vertebrae and sacrum
60
Which kidney is lower on an AXR?
Right due to presence of liver
61
Where is the spleen located?
located in LUQ, superior to left kidney
62
Which bones are visible on an AXR?
* Ribs * Lumbar vertebrae * Sacrum * Coccyx * Pelvis * Proximal femurs
63
What structure can be used to locate the **vesicoureteric junction** on an AXR?
ischial spines (asterisks & arrows at bottom)
64
What are the 2 causes of **added** densities on an AXR?
1. Calcified soft tissue 2. Artefacts e.g. medical device
65
Give some examples of structures that can calcify in an AXR
* Calcified gallstones in RUQ * Renal stones/staghorn calculi * Pancreatic calcification * Vascular calcification * Costochondral calcification
66
What % of renal calculi are idiopathic?
90%
67
give some other causes of renal calculi
* Hyperparathyroidism * Vitamin D excess * Primary hyperoxaluria
68
What are staghorn calculi?
complex renal stones that occupy the majority of the renal collecting system
69
Complications of staghorn calculi?
* High morbidity * Can lead to recurrent UTIs, urosepsis, renal deterioration and death if left untreated
70
What % of gallstones are visible on an AXR?
Only 10% of gallstones contain enough calcium to be visible on AXR
71
Gold standard imaging for gallstones?
US
72
What is the calcification of arteries seen on xrays a sign of?
more generalised atherosclerosis: * Diabetes * Chronic renal failure
